Uniview
Uniview ISW5000-8GT4GP-POE-IN PoE Switch
Uniview ISW5000-8GT4GP-POE-IN PoE Switch — görsel 2
Uniview ISW5000-8GT4GP-POE-IN PoE Switch — görsel 3
1 / 3
PoE Switch

Uniview ISW5000-8GT4GP-POE-IN PoE Switch

ModelISW5000-8GT4GP-POE-IN

Uniview ISW5000-8GT4GP-POE-IN gigabit bir PoE switch'tir. PoE portları IP kamera, access point ve IP telefon gibi cihazları tek ağ kablosu üzerinden besler; toplam PoE bütçesi 120 W.

Port hızı
Gigabit
PoE
PoE
Fiyat ve stok bilgisi alınAynı gün dönüş

Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.

Ara
Distribütör garantili
81 ile sevkiyat
Teknik destek
  • PoE supports IEEE 802.3af/at standards and provides a maximum output of 30W for each port.
  • Data transmission and power supply distance up to 100 meters.
  • Supports IEEE802.3x full-duplex flow control and Backpressure half-duplex flow control.
  • Panel indicators monitor working status and assist in fault analysis.
  • Supports one-click ring network and one-click storm suppression, featuring redundancy and high reliability.
  • Highly reliable design, supporting traditional STP/MSTP/RSTP Layer 2 link protection technology.
  • Support static convergence and dynamic convergence (LACP) 2 convergence modes, effectively increase the link bandwidth, improve the reliability of the link, and at the same time can achieve load balancing, link backup.
  • Flexible and convenient management and maintenance Supports various management modes, such as Console, Telnet, and SSH.

Teknik özellikler

Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.

Genel 2 satır
ModelISW5000-8GT4GP-POE-IN
Ürün Tanımı (Üretici)Harsh PoE Switch
Donanım Özellikleri 16 satır
StandartlarIEEE802.3、IEEE802.3u、IEEE802.3z、IEEE802.3ab、IEEE802.3x、IEEE802.3af、IEEE802.3at
Port Tipi8*10/100/1000Mbps RJ45 Ports; 4*1000Mbps SFP Slots
Anahtarlama Kapasitesi24Gbps
Jumbo Frame9KBytes
İletim Performansı17.86Mpps
MAC Adres Tablosu8K
Transfer ModeStore-and-forward
Maks. PoE GücüMax capacity: 120W; Max capacity for single port: 30W; Mode A 1/2（-），3/6（+）
Boyutlar (G×D×Y)145*109*62.3mm
Çalışma Sıcaklığı-30°C to 65 °C
Çalışma Nemi5% ~ 95% non-condensing
Depolama Nemi0% ~ 95% non-condensing
GöstergePWR, LNK/ACT
Electrostatic StandardContact ±6KV, Air ±8KV
Aşırı Gerilim KorumasıDifferential mode ±2KV Common mode ±4KV
Güç KaynağıDC:48-57V,; Adapter: AC100-240V, 50/60Hz
Yazılım Özellikleri 44 satır
MAC AddressMAC Aging Time; MAC Filter; MAC Notification
Basic ManagementConsole/Telnet/SSH; Http/Https、SSL/TLS; FTP/TFTP; Syslog; SNMP(v1/v2c/v3)、SNMP Trap; SNTP/NTP; CPU protect; Software/Hardware watchdog; Firmware Upgrade/Backup; Ping/Traceroute
Port ConfigBandwidth Control; Flow Control; EEE; MTU; CFM(802.1ag); EFM OAM(802.3ah); DDM; Storm Control; Port Isolation; Port Security; Virtual Cable Test; ULDP
DiscoveryLLDP(802.1ab); LLDP-MED
Link AggregationStatic; LACP(802.3ad); Load Balance(src-mac/dst-mac/src-ip/dst-ip); Max groups and ports per group
VLANVLAN(802.1Q 4K); Access/Trunk/Hybrid; Private VLAN; VLAN Filter; MAC-based VLAN; Protocol-based VLAN; IP Subnet-based VLAN; Voice VLAN; GVRP/GMRP; QinQ/Selective-QinQ/Flexible QinQ; VLAN Translation/N:1 VLAN Translation; Guest VLAN
Network Loop DetectionLoopback Detection; ERPS
Spanning TreeSTP/RSTP/MSTP; MSTP Support 64 instance; BPDU Guard/Root Guard/BPDU Tunnel
ARPStatic ARP; ARP Scanning Prevention; ARP Spoofing Prevention; ARP Guard; Gratuitous ARP; Dynamic ARP Inspection; ARP Quantity Control
ICMPAnti ICMP Attack; ICMP Rate Limit; ICMP Unreachable Drop
IP ForwardStatic Route; Route Aggregation
Multicast VALNMulticast VALN
IGMPIGMP SNOOPING V1/V2/V3; Fast Leave; IGMP Proxy
DHCPDHCP Server; DHCPv4 Client/BOOTP; DHCPv4 Relay; DHCPv4 Snooping; DHCPv4 Option 82/43/60/61/67
IPv6 BasicIPv6 ND Snooping
DHCPv6DHCPv6 Relay; DHCPv6 Snooping; IPv6 SAVI; Security RA; DHCPv6 Server
IPv6 Unicast RoutingStatic Route
IPv6 Multicast RoutingMLD v1/V2 Snooping
IPv6 FeaturesSNMP over IPv6 Support; HTTP over IPv6 Support; SSH over IPv6 Support; DNS over IPv6 Support; IPv6 ping/traceroute Support; IPv6 Telnet Support; IPv6 Radius+ Support; IPv6 Tacacs+ Support; IPv6 SNTP/NTP Support; IPv6 FTP/TFTP Support; IPv6 IPSec Support; IPv6 ACL
BasicTrust COS/DSCP; Trust Port
SchedulingSP; WRR; WDRR
PolicyMap StreamBased on VLAN; Based on COS/DSCP; Aggregate PolicyMap; Ingress PolicyMap
PolicingCAR Stream Shaping(leak algorithm); Ingress Policing
RewriteCOS/802.1p Priority; IP Precedence; IPv4 DSCP/IPv6 DSCP; drop-precedence; internal-priority; Ingress/Egress Rewrite
QueuingDSCP to DSCP mapping; DSCP to DP mapping; DSCP to Queue mapping; COS to DP mapping; COS to Queue mapping
IP-ACLSIP/DIP; IP Protocol; IP Priority(DSCP,TOS, Precedence); TCP,UDP src,dst Port
MAC-ACLSRC/DST MAC; VLAN; COS; Tag/Untag
IP-MAC ACLMAC-ACL and IP-ACL
User-defined ACLBase on user defined profile
ACL FeaturesBased on time period ACL; ACL on VLAN; Based on ACL Stream
802.1xPort Based Authentication; Support EAPoR; MAC based Authentication; Guest VLAN
MABBased on Port Authentication; Based on MAC Authentication
MAC Address Count LimitBased on Port; Based on VLAN
IP Address Count LimitBased on Port; Based on VLAN
Access ManagementBased on source mac and IP address
Deny DoS AttackTCP Flag; TCP Flagment; IP Segment; ICMP
TACACS+Standard Support
RadiusStandard Support; Client, Support MD5
SSLOpenssl 1.1.0
MRPPCompatiable ERRP
ULPPUplink Protection Protocol; Smart Link/Monitor Link
ULSMUplink State Monitor
MirrorSupport one to one, multi to one; Port based mirror, support ingress, egress, and both; CPU based mirror; Flow based mirror; RSPAN
PoE ManagementON/OFF Config; Alive Checking for PD; 7/24 On/Off Scheduling

Genel bakış

Uniview ISW5000-8GT4GP-POE-IN kullanım alanları ve özellikleri.

Uniview ISW5000-8GT4GP-POE-IN, poe switch modelidir. Öne çıkanlar: portlar 8*10/100/1000Mbps RJ45 Ports; 4*1000Mbps SFP Slots.

Üretici tanımı: Harsh PoE Switch

Öne Çıkan Özellikler

  • PoE supports IEEE 802.3af/at standards and provides a maximum output of 30W for each port.
  • Data transmission and power supply distance up to 100 meters.
  • Supports IEEE802.3x full-duplex flow control and Backpressure half-duplex flow control.
  • Panel indicators monitor working status and assist in fault analysis.
  • Supports one-click ring network and one-click storm suppression, featuring redundancy and high reliability.
  • Highly reliable design, supporting traditional STP/MSTP/RSTP Layer 2 link protection technology.
  • Support static convergence and dynamic convergence (LACP) 2 convergence modes, effectively increase the link bandwidth, improve the reliability of the link, and at the same time can achieve load balancing, link backup.
  • Flexible and convenient management and maintenance Supports various management modes, such as Console, Telnet, and SSH.
  • Supports WEB management, which is simple and efficient, and facilitates installation and debugging by engineering and maintenance personnel.
  • Supports file upload and download management through TFTP.

Nerelerde kullanılır?

IP kamera, access point ve IP telefon projelerinde cihazlara tek kablodan enerji ve veri taşır; NVR ile kameralar arasında dağıtım katmanı oluşturur.

Tüm özellikler

  • PoE supports IEEE 802.3af/at standards and provides a maximum output of 30W for each port.
  • Data transmission and power supply distance up to 100 meters.
  • Supports IEEE802.3x full-duplex flow control and Backpressure half-duplex flow control.
  • Panel indicators monitor working status and assist in fault analysis.
  • Supports one-click ring network and one-click storm suppression, featuring redundancy and high reliability.
  • Highly reliable design, supporting traditional STP/MSTP/RSTP Layer 2 link protection technology.
  • Support static convergence and dynamic convergence (LACP) 2 convergence modes, effectively increase the link bandwidth, improve the reliability of the link, and at the same time can achieve load balancing, link backup.
  • Flexible and convenient management and maintenance Supports various management modes, such as Console, Telnet, and SSH.
  • Supports WEB management, which is simple and efficient, and facilitates installation and debugging by engineering and maintenance personnel.
  • Supports file upload and download management through TFTP.

Dokümanlar

Veri sayfası ve kullanım kılavuzları.

Datasheet (Teknik Föy) - UNV ISW5000-8GT4GP-POE-IN Harsh Fast Ring Managed PoE Switch.pdfPDF · ISW5000-8GT4GP-POE-IN

Sık sorulanlar

ISW5000-8GT4GP-POE-IN hakkında kısa yanıtlar.

ISW5000-8GT4GP-POE-IN IP kamera beslemek için uygun mu?
Evet. PoE portları IP kameraları tek kablo üzerinden besler; toplam PoE bütçesi 120 W olduğundan kamera tüketimlerinin toplamı bu değerin altında kalmalıdır.
ISW5000-8GT4GP-POE-IN fiyatı ne kadar?
ISW5000-8GT4GP-POE-IN için fiyat; adet, proje kapsamı ve güncel kura göre değiştiğinden teklif usulüyle verilir. Ürünü teklif listenize ekleyerek veya telefon/WhatsApp hattımızdan ulaşarak aynı iş günü içinde fiyat ve stok bilgisi alabilirsiniz.
