Ziton CP-132UL-I-V2 Haberleşme Modülü

Ziton CP-132UL-I-V2 (ZP3 - Panels Comp. & Acc. ailesi), haberleşme modülü ürünüdür.

Overview

The Z-PCRS485-2 is a universal PCI board which is designed for industrial automation applications that require a long distance, multi-point, PC-based data acquisition solution. Which makes it very suitable for use with the ZP3 fire panel network.

On-chip Automatic Data Direction Control

RS-485 communication requires precise timing control to enable and disable the line driver. The Moxa Turbo Serial Engine™ chip that powers the Z-PCRS485-2 board comes with on-chip ADDC®, which makes RS-485 as easy to use as RS-232.

RS-485 multidrop up 1.2 km

The Z-PCRS485-2 universal PCI boards have 2 RS-422/485 serial ports, each of which can achieve data rates up to 921.6 Kbps. In RS-485 mode, the board can connect up to 31 daisy-chained RS-485 devices within a range of 1.2 km. It also comes with 2 KV optical isolation protection to prevent equipment damage.

Öne Çıkan Özellikler

• Over 800 Kbps data throughput for top performance
• 921.6 Kbps maximum baudrate for super fast data transmission
• ADDC® provides automatic data direction control for RS-485 signals
• Transmit data up to 1.2 km with RS-422/485
• 128-byte FIFO and on-chip H/W, S/W flow control
• Compatible with 3.3/5V PCI and PCI-X
• 15 KV ESD protection on the board

Nerelerde kullanılır?

Yangın algılama sisteminde giriş/çıkış kontrolü, loop izolasyonu veya kurulum aksesuarı olarak kullanılır.

Kurulum ve uyumluluk

Yangın algılama sistemleri; Binaların Yangından Korunması Hakkında Yönetmelik ve TS EN 54 standardına uygun olarak projelendirilmeli ve yetkili ekiplerce devreye alınmalıdır.
